BPMN Icons

Human Task

A work step that humans are in charge of. Generates an input form (Operating screen) automatically in accordance with the editing permission settings on Data Items. When the allocated operator fills out the form and finishes the Task, the token advances.Capable of setting branching by Operator’s choice upon finishing the Task, and also a deadline.

Team Swimlane

Bundles Tasks which members of a team of particular workers will be in charge of. In principle, the token advances when a single user finishes handling the Tasks in a Team Swimlane. The team of Operators is set using the information of Organization and Role and the relationship with the Operator of other Swimlanes.

Message Start Event (Webhook)

Issues a URL that awaits Webhook (HTTP request) in a specified method. Starts a new Process automatically when a Webhook is received. Capable of storing the received request body in a String-type Data Item. Also possible to return an HTTP response with Business Data inserted.

Receive Task (Webhook)

Holds the token and awaits a webhook (HTTP request) at a specific URL. Advances the token when a webhook for the specified HTTP method is received. Capable of storing the received request body in a String-type Data Item. Also possible to return an HTTP response with Business Data inserted.

Swimlane

Bundles Tasks which particular worker will be in charge of. In principle, a single user handles Tasks in a Swimlane. The Operator is set using the information of Organization and Role and the relationship with the Operator of other Swimlanes.

Receive Task (FORM)

Publishes a Web form when a token arrives and awaits input to the web form. Advances the token if there is an input to the web form. The Web form can be submitted by users who don’t have an account for the Workflow platform. The user is notified of the web form URL by email, etc.

Script Task

Executes ECMAScript (program) on the server side and updates business data automatically. Capable for more complex processing than [Service Task (Data Assignment)] such as conditional branching and repetition processing, HTTP communication with the outside, email transmission, etc.

Service Task (PDF Generation)

Inserts business data into a Base PDF form and automatically generate a new PDF file. Although Adobe Acrobat etc. are needed for the preparation of a Base PDF, it is also possible to download a Base PDF with selecting fields from the setting screen, unless you do not care about its layout.

Service Task (Choices Update)

Registers/updates the list of choices specified in the Select type Data Item as an Options Master (Add-on) which is available for Apps common. It needs to be set up by a User with system administration authority.

Service Task (Google Drive: File Upload)

Uploads files specified in File Type Data Item to the specified folder of Google Drive. Capable of obtaining the file ID, the display URL, and the download URL as the response and storing them in a String type Data Item.

Service Task (Data Assignment)

Automatically updates Business Data with the specified value or the evaluation result of the formula. Capable of updating several Data Items also in one automatic Step.

Message Start Event (form)

Issues a Web form (its URL) for awaiting entry. Starts a new process automatically by receiving entry. The form can be embedded on any website using “iframe” HTML tag.

Message Start Event (email)

Starts a new process automatically by receiving an email. Capable of storing the address of the received email, subject, text body, and file attachment as Data Items.

Message Start Event (HTTP)

Issues a URL that awaits an HTTP request. Starts a new Process automatically when an HTTP request is received. Capable of inserting values accepted as receive parameters to Business Data.

OR Gateway

Of the multiple paths, the token is split and moves to all of the paths which satisfy conditions. Workflow may become parallel processing.

AND Gateway

Of the multiple paths, the token is split and moves to all of the paths. Workflow become parallel processing.

XOR Gateway

Of the multiple paths, the token moves to one of the paths that first satisfies the conditional expression.

Timer Start Event

Starts a new Process at the specified time. Applies the repetition rule such as daily, weekly on Monday, or the first day of a month.

Catching Message Intermediate Event (HTTP)

Holds a token and listens for HTTP requests at a specific URL. Receiving an HTTP request, the token advances. Capable of receiving values in parameters and overwriting business data.
