Email-HTML String, Create SimpleNotice
Assembles HTML text for email from workflow data. The html text will consist of blocks of abstract, image, main sentence, link button, and sub-sentence. If the setting is blank, the block will not be displayed.
Configs
- A1: Set Magazine Title (e.g. “SaaS News”) *#{EL}
- A2: Set Magazine Color (e.g. “#009900”)#{EL}
- A3: Set Magazine Font (e.g. “Arial”)#{EL}
- A4: Set Magazine Logo Url (eg https://example.com/example.png )#{EL}
- B1: Set Subject (eg. “Questetra v13 Automatic Start Enhanced”) *#{EL}
- B2: Set Abstract (Line breaks are automatically converted to br)#{EL}
- B3: Set Image Url (e.g. https://example.com/example.png )#{EL}
- B4: Set Section1 (e.g. “About New Feature”)#{EL}
- B5: Set Paragraph1#{EL}
- B6: Set LinkButton Text#{EL}
- B7: Set LinkButton URL#{EL}
- B8: Set Section2 (e.g. “About Questetra”)#{EL}
- B9: Set Paragraph2#{EL}
- C1: Set Publisher Name (e.g. “Questetra, Inc.”) *#{EL}
- C2: Set Publisher Url (e.g. https://example.com/ ) *#{EL}
- C3: Set Publisher Statement#{EL}
- D: Select STRING DATA that stores Email-HTML (update) *
Script (click to open)
// GraalJS Script (engine type: 2)
//////// START "main()" /////////////////////////////////////////////////////////////////
main();
function main(){
//// == Config Retrieving / 工程コンフィグの参照 ==
let strMagazineTitle = configs.get( "StrConfA1" ); /// REQUIRED
strMagazineTitle = encodeHTML( strMagazineTitle );
if( strMagazineTitle === "" ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {A1: MagazineTitle} is empty \n" );
}
let strMagazineColor = configs.get( "StrConfA2" ).replace(/\"/g, ""); // NotRequired
if( strMagazineColor === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {A2: MagazineColor} is empty (default '#009900' applied)" );
strMagazineColor = "#009900";
}
let strMagazineFont = configs.get( "StrConfA3" ).replace(/\"/g, "'"); // NotRequired
if( strMagazineFont === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {A3: MagazineFont} is empty (default applied)" );
strMagazineFont = "Arial, -apple-system, Meiryo, Helvetica, sans-serif";
}
const strLogoUrl = configs.get( "StrConfA4" ); // NotRequired
if( strLogoUrl === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {A4: LogoUrl} is empty" );
}
let strSubject = configs.get( "StrConfB1" ); /// REQUIRED
strSubject = encodeHTML( strSubject );
if( strSubject === "" ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {B1: Subject} is empty \n" );
}
let strAbstract = configs.get( "StrConfB2" ); // NotRequired
if( strAbstract === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {B2: Abstract} is empty" );
}else{
strAbstract = encodeHTML( strAbstract ).replace(/\n/g, '<br>\n');
strAbstract = convertMultiSpaces( strAbstract );
}
const strImageUrl = configs.get( "StrConfB3" ); // NotRequired
if( strImageUrl === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {B3: ImageUrl} is empty" );
}
let strSection1 = configs.get( "StrConfB4" ); // NotRequired
if( strSection1 === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {B4: Section1} is empty" );
}else{
strSection1 = encodeHTML( strSection1 );
}
let strParagraph1 = configs.get( "StrConfB5" ); // NotRequired
if( strParagraph1 === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {B5: Paragraph1} is empty" );
}else{
strParagraph1 = encodeHTML( strParagraph1 ).replace(/\n/g, '<br>\n');
strParagraph1 = convertMultiSpaces( strParagraph1 );
}
let strLinkButtonText = configs.get( "StrConfB6" ); // NotRequired
strLinkButtonText = encodeHTML( strLinkButtonText );
if( strLinkButtonText === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {B6: LinkButtonText} is empty" );
}
const strLinkButtonUrl = configs.get( "StrConfB7" ); // NotRequired
if( strLinkButtonUrl === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {B7: LinkButtonUrl} is empty" );
}
if( strLinkButtonText === "" && strLinkButtonUrl !== "" ){
strLinkButtonText = strLinkButtonUrl;
}
let strSection2 = configs.get( "StrConfB8" ); // NotRequired
if( strSection2 === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {B4: Section2} is empty" );
}else{
strSection2 = encodeHTML( strSection2 );
}
let strParagraph2 = configs.get( "StrConfB9" ); // NotRequired
if( strParagraph2 === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {B5: Paragraph2} is empty" );
}else{
strParagraph2 = encodeHTML( strParagraph2 ).replace(/\n/g, '<br>\n');
strParagraph2 = convertMultiSpaces( strParagraph2 );
}
let strPublisherName = configs.get( "StrConfC1" ); /// REQUIRED
strPublisherName = encodeHTML( strPublisherName );
if( strPublisherName === "" ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {C1: PublisherName} is empty \n" );
}
const strPublisherUrl = configs.get( "StrConfC2" ); /// REQUIRED
if( strPublisherUrl === "" ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {C2: PublisherUrl} is empty \n" );
}
let strPublisherStatement = configs.get( "StrConfC3" ); // NotRequired
if( strPublisherStatement === "" ){
engine.log( " AutomatedTask ConfigWarning: " +
" {C3: PublisherStatement} is empty" );
}else{
strPublisherStatement = encodeHTML( strPublisherStatement ).replace(/\n/g, '<br>\n');
strPublisherStatement = convertMultiSpaces( strPublisherStatement );
}
const strPocketHtml = configs.getObject( "SelectConfD" ); /// REQUIRED
//// == Data Retrieving / ワークフローデータの参照 ==
// (Nothing. Retrieved via Expression Language in Config Retrieving)
//// == Calculating / 演算 ==
// Build HTML String with Template_literals (ES6)
// ${strMagazineTitle}
// ${strMagazineColor}
// ${strMagazineFont}
// ${strLogoUrl}
// ${strSubject}
// ${strAbstract}
// ${strImageUrl}
// ${strSection1}
// ${strParagraph1}
// ${strLinkButtonText}
// ${strLinkButtonUrl}
// ${strSection2}
// ${strParagraph2}
// ${strPublisherName}
// ${strPublisherUrl}
// ${strPublisherStatement}
let strBlockHeader = `<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN"
"http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd"><html><head>
<meta http-equiv="Content-Type" content="text/html; charset=UTF-8">
<meta http-equiv="Content-Style-Type" content="text/css">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<title>${strMagazineTitle}</title>
</head><body bgcolor="#ffffff"
style="background-color:#ffffff; margin:0 auto; padding:0; width:100%; font-family:${strMagazineFont}">
<table width="640" border="0" align="center" cellpadding="0" cellspacing="0" bgcolor="#ffffff"
style="width:100%; max-width:640px; border:none; margin:0 auto; padding:0; background-color:#ffffff">
`;
let strBlockLogo = `<tr><td height="8" style="height:0.5em"></td></tr>
<tr><td width="100%" style="width:100%; margin:0; padding:0">
<img src="${strLogoUrl}" alt="Logo Image" style="max-width:100%; height:auto">
</td></tr>
<tr><td height="8" style="height:0.5em"></td></tr>
`;
let strBlockSubject = `<tr><td height="8" style="height:0.5em"></td></tr>
<tr><td style="font-family:${strMagazineFont}">
${strMagazineTitle}
</td></tr>
<tr><td>
<h2 style="font-size:1.8em; color:${strMagazineColor}; font-family:${strMagazineFont}">
${strSubject}</h2>
</td></tr>
`;
let strBlockAbstract = `<tr><td style="font-family:${strMagazineFont}">
${strAbstract}
</td></tr>
`;
let strBlockImage = `<tr><td height="8" style="height:0.5em"></td></tr>
<tr><td
width="100%" style="width:100%; margin:0; padding:0">
<table width="100%" border="0" align="center" cellpadding="0" cellspacing="0" bgcolor="#ffffff"
style="width:100%; border:none; margin:0 auto; padding:0; background-color:#ffffff">
<tr><td width="5%"></td>
<td width="90%">
<img src="${strImageUrl}" alt="Featured Image" style="max-width:100%">
</td>
<td width="5%"></td></tr>
</table>
</td></tr>
<tr><td height="8" style="height:0.5em"></td></tr>
`;
let strBlockSection1 = `<tr><td height="8" style="height:0.5em"></td></tr>
<tr><td>
<h3 style="font-size:1.6em; font-family:${strMagazineFont}">
${strSection1}</h3>
</td></tr>
`;
let strBlockParagraph1 = `<tr><td style="font-family:${strMagazineFont}">
${strParagraph1}
</td></tr>
`;
let strBlockLinkButton = `<tr><td height="16" style="height:1.0em"></td></tr>
<tr><td
width="100%" align="center"
style="width:100%; margin:0px auto">
<a href="${strLinkButtonUrl}"
style="display:inline-block; font-weight:bold; border-radius:8px; padding:10px 20px;
color:#ffffff; background:${strMagazineColor}; border:solid 4px ${strMagazineColor}">
${strLinkButtonText}</a>
</td></tr>
<tr><td height="16" style="height:1.0em"></td></tr>
`;
let strBlockSection2 = `<tr><td height="8" style="height:0.5em"></td></tr>
<tr><td>
<h3 style="font-size:1.6em; font-family:${strMagazineFont}">
${strSection2}</h3>
</td></tr>
`;
let strBlockParagraph2 = `<tr><td style="font-family:${strMagazineFont}">
${strParagraph2}
</td></tr>
`;
let strBlockFooter = `<tr><td height="32" style="height:2.0em"></td></tr>
<tr><td height="24" bgcolor="#eeeeee" style="height:1.5em; background:#eeeeee"></td></tr>
<tr><td
width="100%" align="center" bgcolor="#eeeeee"
style="width:100%; text-align:center; background:#eeeeee; font-size:.8em">
<a href="${strPublisherUrl}">${strPublisherName}</a>
</td></tr>
<tr><td
width="100%" align="center" bgcolor="#eeeeee"
style="width:100%; text-align:center; background:#eeeeee; font-size:.7em">
${strPublisherStatement}
</td></tr>
<tr><td height="24" bgcolor="#eeeeee" style="height:1.5em; background:#eeeeee"></td></tr>
<tr><td height="24" style="height:1.5em"></td></tr>
</table></body></html>
`;
let strHtml = strBlockHeader;
if( strLogoUrl !== "" ){
strHtml += strBlockLogo;
}
strHtml += strBlockSubject;
if( strAbstract !== "" ){
strHtml += strBlockAbstract;
}
if( strImageUrl !== "" ){
strHtml += strBlockImage;
}
if( strSection1 !== "" ){
strHtml += strBlockSection1;
}
if( strParagraph1 !== "" ){
strHtml += strBlockParagraph1;
}
if( strLinkButtonUrl !== "" ){
strHtml += strBlockLinkButton;
}
if( strSection2 !== "" ){
strHtml += strBlockSection2;
}
if( strParagraph2 !== "" ){
strHtml += strBlockParagraph2;
}
strHtml += strBlockFooter;
//// == Data Updating / ワークフローデータへの代入 ==
engine.setData( strPocketHtml, strHtml );
} //////// END "main()" /////////////////////////////////////////////////////////////////
function encodeHTML( str ){
return str.replace(/&/g, '&')
.replace(/</g, '<')
.replace(/>/g, '>')
.replace(/"/g, '"')
.replace(/'/g, ''');
}
// convert multiple consecutive spaces to " .."
function convertMultiSpaces( strArg ){
let re = /\ {2,}/g;
// let re = /s{2,}/g;
let strReturn = strArg.replace( re, function( strMatch ){
let strNbspSpRepeat = "";
for( let i = 0; i < strMatch.length; i++ ){
if( (i % 2) === 0 ){ // Even number
strNbspSpRepeat += " ";
}else{ // Odd number
strNbspSpRepeat += " ";
}
}
return strNbspSpRepeat;
});
return strReturn;
}
/*
Notes:
- When a token reaches the automated step, the code for HTML mail is automatically generated.
- The generated code can be set in "Message Sending Intermediate Event (Email)" (v13.1) as it is.
- https://support.questetra.com/bpmn-icons/throwing-message-intermediate-event-email/
- It is also effective to add a human step in downstream to add decorative tags such as strong and span.
- Special characters in workflow data are escaped as appropriate.
- For example, "<" is automatically converted to "<".
- Line feed codes in multi-line text are automatically converted to br tags.
- Multiple spaces (two or more spaces) in workflow data are replaced with " " every other character.
- eg "A B C D" to "A B C D"
APPENDIX
- The generated HTML code is not guaranteed to be displayed properly in all mailers.
- The HTML code is built on the basis of 640px wide table tags.
- Basically, the background color is white and the text color is black.
- Subjects (titles) in the email body will be displayed in the color specified in MagazineColor.
- The link button in the email will be displayed in the color specified in MagazineColor.
- MagazineLogo image is displayed in its original size.
- Image with a width greater than 640px will be scaled down.
- As a guide, the height should be between 20px and 50px.
- The URL of the MagazineLogo image must be accessible to the recipient.
Notes-ja:
- 案件が自動処理工程に到達した際、HTMLメール用のコードが自動的に生成されます。
- 生成されたコードは、そのまま『メッセージ送信中間イベント(メール)』(v13.1)にセットできます。
- https://support.questetra.com/ja/bpmn-icons/throwing-message-intermediate-event-email/
- 下流に "装飾タグを手動追加する工程"(strong や span など)を配置するのも効果的です。
- ワークフローデータ内の特殊文字は、適宜エスケープ処理されます。
- たとえば、"<" は "<" に自動的に変換されます。
- 複数行テキスト内の改行コードは、自動的に br タグに変換されます。
- ワークフローデータ内の連続スペース(2文字以上)は、一文字おきに " " に置換されます。
- eg "A B C D" to "A B C D"
APPENDIX-ja
- 生成されるHTML コードは、全てのメーラで正常に表示されることが保証されている訳ではありません。
- HTML コードは、640px 幅の table タグがベースとなって組み立てられます。
- 背景色は白、文字色は黒が基本となります。
- メール内に再掲されるサブジェクト(タイトル)は、MagazineColor で指定した色で表示されます。
- メール内に表示されるリンクボタンは、MagazineColor で指定した色で表示されます。
- Magazine Logo 画像は、そのままのサイズで表示されます。
- 幅が 640px を超える画像は縮小表示されます。
- 高さが 20px から 50px が目安となります。
- Magazine Logo 画像の URL は、受信者がアクセスできるURLでなければなりません。
*/
Download
2021-06-20 (C) Questetra, Inc. (MIT License)
https://support.questetra.com/addons/email-html-string-create-simplenotice-2021/
The Addon-import feature is available with Professional edition.
Notes
- When a token reaches the automated step, the code for HTML mail is automatically generated.
- The generated code can be set in “Message Sending Intermediate Event (Email)” (v13.1) as it is.
- https://support.questetra.com/bpmn-icons/throwing-message-intermediate-event-email/
- It is also effective to add a human step in downstream to add decorative tags such as strong and span.
- Special characters in workflow data are escaped as appropriate.
- For example, “<” is automatically converted to “
<
“. - Line feed codes in multi-line text are automatically converted to br tags.
- For example, “<” is automatically converted to “
- Multiple spaces (two or more spaces) in workflow data are replaced with “
” every other character.- eg “A B C D” to “
A B C D
“
- eg “A B C D” to “
Capture


Appendix
- The generated HTML code is not guaranteed to be displayed properly in all mailers.
- The HTML code is built on the basis of 640px wide table tags.
- Basically, the background color is white and the text color is black.
- Subjects (titles) in the email body will be displayed in the color specified in MagazineColor.
- The link button in the email will be displayed in the color specified in MagazineColor.
- MagazineLogo image is displayed in its original size.
- Image with a width greater than 640px will be scaled down.
- As a guide, the height should be between 20px and 50px.
- The URL of the MagazineLogo image must be accessible to the recipient.
Pingback: Email-HTML String, Create ImageList – Questetra Support
Pingback: Email-HTML String, Create TsvTable – Questetra Support
Pingback: Let’s Send an Email Automatically in the Middle of a Workflow (HTML Email chapter) – Questetra Support
Pingback: Email-HTML String, Create DataitemList – Questetra Support
