TSV 文字列, 数値列のサマリ集計表を生成 (TSV String, Create Summary Table for Numeric Column)
数値列の値をキー列で集約します。「合計値」「合計値が全体に占める割合」「データ個数」「データ平均値」をサマリ集計表TSVとして出力します。たとえば「売上ログTSV」から「取引先ごとの売上高」といった集計値が自動的に出力されます。(単純集計/GT集計)
Configs
- A1: TSVをセットしてください *#{EL}
- B1: 数値フィールドの列IDをセットしてください (例 “3” ) *#{EL}
- B2: 集約Keyフィールドの列IDをセットしてください (例 “4” ) *#{EL}
- C1: 合計値でソートする場合は降順(DESC)もしくは昇順(ASC)をセットしてください (例 “ASC” )#{EL}
- C2: 集約Keyでソートする場合は降順(DESC)もしくは昇順(ASC)をセットしてください (例 “ASC” )#{EL}
- D1: サマリ集計TSVが格納される文字列型データ項目を選択してください (更新) *
- D2: 総合計が格納される数値型データを選択してください (更新)
Script (click to open)
// GraalJS Script (engine type: 2)
//////// START "main()" /////////////////////////////////////////////////////////////////
main();
function main(){
//// == Config Retrieving / 工程コンフィグの参照 ==
const strTsv = configs.get( "StrConfA1" ); /// REQUIRED /////////////
if( strTsv === "" ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {A1: Tsv} is empty \n" );
}
const arr2dTsv = parseAsRectangular( strTsv );
const strNumField = configs.get( "StrConfB1" ); /// REQUIRED /////////////
if( strNumField === "" ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {B1: NumField} is empty \n" );
}
const numNumField = parseInt( strNumField, 10 );
if( isNaN( numNumField ) || numNumField < 0 ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {B1: NumField} must be a positive integer \n" );
}
if( numNumField >= arr2dTsv[0].length ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {B1: NumField} is larger than TsvWidth \n" );
}
const strYaggField = configs.get( "StrConfB2" ); /// REQUIRED /////////////
if( strYaggField === "" ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {B2: Y-AggField} is empty \n" );
}
const numYaggField = parseInt( strYaggField, 10 );
if( isNaN( numYaggField ) || numYaggField < 0 ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {B2: YaggField} must be a positive integer \n" );
}
if( numYaggField >= arr2dTsv[0].length ){
throw new Error( "\n AutomatedTask ConfigError:" +
" Config {B2: YaggField} is larger than TsvWidth \n" );
}
const strNumSort = configs.get( "StrConfC1" ); // NotRequired ///////////
const strYaggSort = configs.get( "StrConfC2" ); // NotRequired ///////////
const strPocketOutput = configs.getObject( "SelectConfD1" ); // NotRequired ///////
const numPocketGrandTotal = configs.getObject( "SelectConfD2" ); // NotRequired ///////
//// == Data Retrieving / ワークフローデータの参照 ==
// (Nothing. Retrieved via Expression Language in Config Retrieving)
//// == Calculating / 演算 ==
// omit repeated Keys in Y-Aggregation Field values (make Keys uniq)
let arrYaggKeys = [];
for( let i = 0; i < arr2dTsv.length; i++ ){
if( arrYaggKeys.indexOf( arr2dTsv[i][ numYaggField ] ) === -1){
arrYaggKeys.push( arr2dTsv[i][ numYaggField ] );
}
// Array.indexOf(): strict equality `===`
// https://developer.mozilla.org/docs/Web/JavaScript/Reference/Global_Objects/Array/indexOf
}
// sort by Keys
if( strYaggSort === "ASC" ){ // ASC: ascending alphabetical from A to Z
arrYaggKeys.sort( function( strA, strB ){
if( strA > strB ){ return 1; }
if( strA < strB ){ return -1; }
return 0;
});
}
if( strYaggSort === "DESC" ){ // DESC: descending from Z to A
arrYaggKeys.sort( function( strA, strB ){
if( strA < strB ){ return 1; }
if( strA > strB ){ return -1; }
return 0;
});
}
// initialize arr2dOutput[y][x]
let arr2dOutput = [];
for( let i = 0; i < arrYaggKeys.length; i++ ){
arr2dOutput[i] = [];
arr2dOutput[i][0] = arrYaggKeys[i];
arr2dOutput[i][1] = 0; // sum
arr2dOutput[i][2] = 0; // share
arr2dOutput[i][3] = 0; // count
arr2dOutput[i][4] = 0; // ave
} // arr2dOutput.length === arrYaggKeys.length
// sum up
let numGrandTotal = 0;
for( let i = 0; i < arr2dTsv.length; i++ ){
let numValue = parseFloat( arr2dTsv[i][numNumField].replace(/,/g, '') );
if( isNaN(numValue) ){
engine.log( " AutomatedTask StringWarning:" +
" CellStr is not numeric at line: " + i );
numValue = 0;
}
let strKey = arr2dTsv[i][numYaggField];
arr2dOutput[ arrYaggKeys.indexOf( strKey ) ][1] += numValue;
arr2dOutput[ arrYaggKeys.indexOf( strKey ) ][3] += 1;
numGrandTotal += numValue;
}
for( let i = 0; i < arr2dOutput.length; i++ ){
arr2dOutput[i][2] = (arr2dOutput[i][1] / numGrandTotal).toFixed(3);
arr2dOutput[i][4] = (arr2dOutput[i][1] / arr2dOutput[i][3]).toFixed(3);
}
// sort by Total
if( strNumSort === "ASC" ){ // ASC: ascending alphabetical from 0 to 10
arr2dOutput.sort( function( arrA, arrB ){
if( arrA[1] > arrB[1] ){ return 1; }
if( arrA[1] < arrB[1] ){ return -1; }
return 0;
});
}
if( strNumSort === "DESC" ){ // DESC: descending from 10 to 0
arr2dOutput.sort( function( arrA, arrB ){
if( arrA[1] < arrB[1] ){ return 1; }
if( arrA[1] > arrB[1] ){ return -1; }
return 0;
});
}
// output Summary Tabulation
let strOutput = "";
for( let i = 0; i < arr2dOutput.length; i++ ){
strOutput += arr2dOutput[i].join("\t") + "\n";
}
strOutput = strOutput.slice( 0, -1 ); // delete last "\n"
//// == Data Updating / ワークフローデータへの代入 ==
engine.setData( strPocketOutput, strOutput );
if( numPocketGrandTotal !== null ){
engine.setData( numPocketGrandTotal, new java.math.BigDecimal( numGrandTotal ) );
}
} //////// END "main()" /////////////////////////////////////////////////////////////////
// Parses TSV string as two-dimensional rectangular data matrix and creates a 2D array.
function parseAsRectangular( strTsv ){
const arrTsv = strTsv.split("\n");
/// Get numMinWidth and numMaxWidth (blank lines are excluded)
let numMinWidth = Infinity; // cf. String-Type Max: 1 million
let numMaxWidth = 0;
let numBlanklines = 0;
for( let i = 0; i < arrTsv.length; i++ ){
if( arrTsv[i] === "" ){ // Skip blank lines
numBlanklines += 1;
continue;
}
let arrCells = arrTsv[i].split("\t");
if( numMinWidth > arrCells.length ){ numMinWidth = arrCells.length; }
if( numMaxWidth < arrCells.length ){ numMaxWidth = arrCells.length; }
}
engine.log( " AutomatedTask TsvDataCheck:" +
" MinWidth:" + numMinWidth +
" MaxWidth:" + numMaxWidth +
" Lines:" + arrTsv.length +
" (BlankLines:" + numBlanklines + ")" );
/// Get numMinWidth and numMaxWidth (blank lines are excluded)
let arr2dTsv = [];
for( let i = 0; i < arrTsv.length; i++ ){
if( arrTsv[i] === "" ){ // Skip blank lines
continue;
}
let arrTmp = [];
let arrCells = arrTsv[i].split("\t");
for( let j = 0; j < numMaxWidth; j++ ){
if( j < arrCells.length ){
arrTmp[j] = arrCells[j];
}else{
arrTmp[j] = "";
}
}
arr2dTsv.push( arrTmp );
}
return arr2dTsv;
}
/*
Notes:
- When the process reaches this automated task, TSV is automatically read.
- TSV: Monthly sales, monthly access log, etc.
- If there is a blank line in the input TSV text, it will be skipped.
- The line feed code for the last line is not added either.
- The output TSV text (total table TSV, etc.) is rectangular data.
- The number of rows in TSV is the number of types of "aggregate Key".
- The number of columns of TSV is 5 of "key", "sum", "percentage", "count", and "average".
APPENDIX:
- TSV (Tab Separated Values) text assumes rectangular data.
- Data that is not rectangular is automatically formatted with empty characters.
- Blank lines (including the end) are ignored.
- Only "DECS" or "ASC" is valid for the sort config.
- If no sort setting, it will be in the order of appearance.
- Character sorting is in code order.
- If both character sort and numeric sort are configured, numeric sort is performed after character sort.
- Specify the field column with the column ID (starting with zero).
- Parsing numeric field values depends on JavaScript `parseFloat()`.
- If commas in the numeric field, they are considered a thousands separator (The removed string is parsed).
- A string that cannot be parsed is considered zero.
Notes-ja:
- 案件が自動処理工程に到達した際、文字列型データに保存されているTSVが自動的に読み込まれます。
- TSV: 月次売上、月次アクセスログ、など
- 入力TSVテキストに空行がある場合、スキップされます。
- 出力TSVの最終行に改行コードは付与されません。
- 出力されるTSVテキスト(合計値テーブルTSV等)は、矩形データです。
- TSVの行数は "集約Key" の種類数になります。
- TSVの列数は、"集約Key列" "合算値列" "割合値列" "個数列" "平均値列" の5です。
APPENDIX-ja:
- TSV(Tab Separated Values)テキストは、矩形データを前提とします。
- 矩形でないデータは、空文字によって自動整形されます。
- 空行(末尾改行を含む)は無視されます。
- ソート設定は "DECS" もしくは "ASC" のみが有効です。
- ソート設定がない場合、出現順になります。
- 文字ソートは文字コード順になります。
- 文字ソートと数値ソートがどちらも設定された場合、文字ソートの後に数値ソートが実行されます。
- フィールド列の指定は、列ID(ゼロ始まり)で設定してください。
- 数値フィールド値の解析(パース)は JavaScript `parseFloat()` に依存します。
- 数値フィールド値にカンマが存在する場合、桁区切り文字とみなされます(除去された文字列が解析されます)。
- 解析できない文字列はゼロと見なされます。
*/
Download
2021-09-06 (C) Questetra, Inc. (MIT License)
https://support.questetra.com/ja/addons/tsv-string-create-summary-table-for-numeric-column-2021/
Addonファイルのインポートは Professional でのみご利用いただけます。
自由改変可能な JavaScript (ECMAScript) コードです。いかなる保証もありません。
Notes
- 案件が自動処理工程に到達した際、文字列型データに保存されているTSVが自動的に読み込まれます。
- TSV: 月次売上、月次アクセスログ、など
- 入力TSVテキストに空行がある場合、スキップされます。
- 出力TSVの最終行に改行コードは付与されません。
- 出力されるTSVテキスト(合計値テーブルTSV等)は、矩形データです。
- TSVの行数は “集約Key” の種類数になります。
- TSVの列数は、”集約Key列” “合算値列” “割合値列” “個数列” “平均値列” の5です。
Capture


Appendix
- TSV(Tab Separated Values)テキストは、矩形データを前提とします。
- 矩形でないデータは、空文字によって自動整形されます。
- 空行(末尾改行を含む)は無視されます。
- ソート設定は “DECS” もしくは “ASC” のみが有効です。
- ソート設定がない場合、出現順になります。
- 文字ソートは文字コード順になります。
- 文字ソートと数値ソートがどちらも設定された場合、文字ソートの後に数値ソートが実行されます。
- フィールド列の指定は、列ID(ゼロ始まり)で設定してください。
- 数値フィールド値の解析(パース)は JavaScript
parseFloat()
に依存します。 - 数値フィールド値にカンマが存在する場合、桁区切り文字とみなされます(除去された文字列が解析されます)。
- 解析できない文字列はゼロと見なされます。
- 数値フィールド値の解析(パース)は JavaScript
